《FI-8》
MODEL：FI-4 / FI-8
| MODEL | FI-4 | FI-8 |
|---|---|---|
| Cutting size | 750~1250mm | 1200~2600mm |
| Cutting thickness | 2~30mm | 2~30mm |
| First circular Saws (Dia. * No.) | 355mm X 1 set | 355mm X 1 set |
| Second circular saws (Dia. * No.) | 250mm X 1 set | 250mm X 1 set |
| R.P.M. of circular saws | 6500 R.P.M | 6500 R.P.M |
| Feeding speed (step-less) | 25~100m/min | 25~100m/min |
| Motor for first circular saws | 7.5KW X 2P X 1set | 7.5KW X 2P X 1set |
| Motor for second circular saws | 3.7KW X 2P X 1set | 3.7KW X 2P X 1set |
| Motor for feeding | 5.5KW X 4P | 5.5KW X 4P |
| Motor for elevating upper roll | 0.75KW X 4P X 1/60 | 0.75KW X 4P X 1/60 |
| Motor for positioning width | 0.75KW X 4P X 1/60 | 0.75KW X 4P X 1/60 |
