《FI-8》
MODEL：FI-4 / FI-8
| MODEL | FI-4 | FI-8 |
|---|---|---|
| Cutting size | 750~1250mm | 1000~2500mm |
| Cutting thickness | 3~25mm | 3~25mm |
| Circular saws (Dia. * No.) | 305mm x 2 sets | 305mm x 2 sets |
| R.P.M. of Circular saws | 6500 R.P.M | 6500 R.P.M |
| Feeding speed (step-less) | 25~100m/min | 25~100m/min |
| Motor for circular saws | 7.5KW X 2P X 2sets | 7.5KW X 2P X 2sets |
| Motor for feeding | 3.7KW X 4P | 3.7KW X 4P |
| Motor for elevating upper roll | 0.75KW x 4P x 1/60 | 0.75KW x 4P x 1/60 |
| Motor for positioning width | 0.75KW x 4P x 1/60 | 0.75KW x 4P x 1/60 |
